  Using the IIoT to Improve Packaging Line Performance

26  July  2019

  Incremental implementation of the IIoT by plant engineers and other experts is the best route to success.

Food packaging plants face a host of challenges in terms of eliminating food waste, improving safety and increasing uptime. These challenges are heightened by a confluence of external factors including pressure on margins, responding to real-time demand, requirements to use sustainable materials and others.

Many of these issues can be addressed by applying the industrial internet of things (IIoT) and related edge technologies in a systematic and incremental manner. Specifically, this will require more comprehensive data collection, reporting and analytics across the supply chain.

This article will first look at issues facing packaging plant managers and other personnel, and will then show how these problems can be solved through the intelligent implementation of IIoT solutions.

Production Challenges

Pressure on margins is a fact of life for most manufacturers, especially in packaging where thin margins are impacted by small changes that can result in significant percentage differences in costs. Margin pressures are heightened by other production improvement initiatives because dealing with these issues usually requires at least some initial outlay in capital or operating expenses.

US EPA 2030 Food Loss & Waste Reduction Goals arenít yet a regulation, but very well may be in the near future. These types of goals should be considered by every packaging plant because when implemented correctly, they can save money and improve the image of the brand name on the package.

Safety is another ongoing issue becoming more important over time. It can be divided into two parts, with the first being the safety of plant personnel, and the second being protection of the product encased in the packaging. As with food loss and waste reduction, improving safety will have an initial cost, but can save money in the long run, and improve or at least maintain brand reputation.

Compliance with the PackML technical standard is becoming a requirement for many packaging plants. Initial standardization efforts and implementations can be burdensome, but when implemented correctly, gains in terms of improved data exchange can outweigh costs.

Pressure to use sustainable materials is growing, and these materials are often harder to work with than traditional solutions. Because many of these materials are relatively new, issues can ripple upstream in the chain as suppliers struggle to provide packaging plants with the right properties in these newer materials.

Another supply chain issue is tracking and tracing not only the contents, but also the packaging materials across the production process, often until a product is purchased by a consumer. While the effects of traditional packaging materials on the products encased was minimal to non-existent, the effects of newer materials are somewhat of an unknown, especially if these materials are biodegradable. These materials are designed to eventually degrade after use and disposal, but if degradation occurs too quickly it can spoil product.

Compounding these sustainable material problems is the ever-growing variety of food products and packages. Where there were once one or two varieties of yogurt, for example, there can now be scores of different variations, with each requiring a slightly different package. Dealing with these variations requires manufacturers to reduce changeover times, minimize downtime and maximize throughput.

Now that weíve looked at some of the leading production challenges found in packaging areas, letís consider solutions.

Acquiring and Using Data

Many of the challenges faced by packaging plant personnel can be addressed by better use of existing data and by acquiring new data, and by subsequently analyzing this data more effectively.

Modern automation packaging plants are typically controlled by programmable logic controllers (PLCs). These controllers not only provide real-time automation, but also act as data collectors and concentrators. Controllers are usually connected to human machine interface (HMI) platforms, often PC-based, but increasingly running on industrial edge computing platforms. Most HMIs come with the hardware connections and software protocols required to send data to data analytics software systems running either on-premises or in the cloud.

An added IIoT implementation is often the best solution when new points of data need to be acquired, stored and analyzed. Itís common to have packaging machines running with just enough data points connected to the PLC to provide real-time automation, but not enough to meet the current and future challenges faced by manufacturers listed above.

Adding these new data points using traditional methods can be cumbersome and expensive. It requires installing a new sensor or instrument, wiring it to the PLC, and configuring the PLC and HMI software to exchange the new data.

The IIoT approach can greatly simplify this process across the engineering life-cycle. New data points can often be added by installing wireless sensors powered with built-in batteries. By configuring update rates to send data only when it changes, sensor batteries can last for up to ten years. Some wireless sensors include energy harvesting components that can scavenge power from vibration or heat to power batteries, extending battery life to decades.

Whether new sensors are wireless or wired, itís often much more cost effective to bypass the PLC and connect them directly to HMIs and other higher-level data collection and analytic computing platforms. In fact, this should be the preferred connection method for all points of data not required for real-time control. These connection methods use either company intranets and/or the internet, putting the ďIĒ into the IIoT.

HMIs and higher-level computing platforms, such as asset management or data analytics software, can be on premises or cloud-based, using either secure intranet or internet connectivity respectively.

Now that weíve examined the mechanics of the IIoT, letís look at how it can be used to address challenges.

Incremental IIoT

Many IIoT implementations fail because they are focused on proving the technology, instead of on the problem and its solution. Itís easy to become overwhelmed with IIoT terminology, from machine learning artificial intelligence to blockchain, and everything in between.

Some vendors tout their technologies and suggest packaging plants must implement them right away or risk being left behind, but the reality is very different. Vendors without substantial knowledge of the particular packaging application often push their technologies because it only requires them to understand how their own products work. This is the easy part.

The hard part is understanding how to address the specific problems and opportunities faced by a particular packaging line, and then providing technology-based solutions to address them. This requires deep domain knowledge, preferably of the entire food/packaging supply chain.

Vendors must work closely with packaging area personnel to incrementally implement IIoT-based solutions. The proposed solutions must be user friendly and not require ongoing support from the vendor or from the plant or corporate IT personnel. Instead, the existing operations technology (OT) personnel in the plant should be able to implement and support the solution, with minimal training required. If this is not the case, the solution is too complex and should not be considered.

Once the right applications and IIoT technologies are selected, implementation needs to be incremental, starting with a well-defined problem and providing a solution. Once this is done, results can be disseminated throughout the company to build interest and enthusiasm for further implementations.

One caution with this approach is to select only those technologies which are scalable, working just as well to solve one simple problem as to solve hundreds of problems across an entire fleet of packaging lines. This is especially important as more complex problems are often solved by simultaneously examining many different data points, in some cases across multiple machines located at different locations.

Scalability requires a computing infrastructure to support existing applications while enabling new IIoT additions. This can often be done by leveraging virtualization, for example. This technology allows multiple applications, and even multiple operating systems, to run on a single virtual machine, usually a PC or server. When a virtual machine is used in this manner, reliability can become even more important, so itís a best practice to use PCs and other computing platforms capable of providing high availability in industrial environments.

As with other technologies, these products should be usable and maintainable by OT personnel while fitting into corporate IT standards. And of course, any IIoT solution must ensure cybersecurity best practices. This is particularly important as IIoT solutions often require sharing data outside the plant walls as they scale.

In some cases, the solutions will require collaboration among plant personnel, technology providers and packaging machine original equipment manufacturers (OEMs), virtually necessitating an IIoT approach to data sharing.

Packaging Problems and IIoT Solutions

The mechanics of IIoT solutions have been discussed, along with the importance of an incremental approach. Letís now look at specific packaging problems, and how the IIoT can be used to provide solutions.

As mentioned, more complex packaging problems often require comparison and contrasting performance from one line to another, with these lines often located in different plants. Remote and edge data collection, with this data provided to the cloud, provides a means to examine performance remotely by multiple experts working collaboratively. Data analytics software can aid this effort by simplifying the task of cleansing and examining data to create new insights.

Providing more in-line quality and performance data for use locally where production occurs, as well as cloud-based analytics across the entire supply and demand chain, will result in better traceability. It will also result in improved matching of production planning and scheduling to meet real-time demand, and can facilitate predictive failure analysis.

A big part of sustainability is monitoring and minimizing energy consumption. This often requires the addition of new data points to monitor temperatures, power usage, steam flows and other variables. Comparing this newly acquired data to utility pricing can help plants optimize energy use. IIoT-based solutions are ideal to address these types of issues because they allow data from many different sources to be examined and analyzed more cost effectively than ever before.

Data acquired by installing sensors, hardware and software can be used to minimize the use of packaging materials, and to simplify material usage across multiple product SKUs.

Minimizing food waste starts with putting precise amounts of products into packages. Too little violates basic rules and laws requiring manufacturers to provide the amounts of products listed on the packages, and too much results in product giveaway, and possibly leakage due to overfilling. The addition of in-line sensors and the analysis of the data they provide can address these issues by helping manufacturers close the loop on product filling.

Conclusion

Improved IIoT sensors, data points and analytics will provide better traceability and demand/supply planning from farm to forkóalong with improved insights into packaging materials, equipment operation, performance and maintenance.

The key is to start small with an incremental approach focused on problems, new opportunities and solutionsóinstead of trying to install all of the latest IIoT technologies at once, and then searching to see if they can be made to work in your packaging area or plant.

For more information, please visit: www.stratus.com
